High Strength-to-lightweight Ratio PA6 CF35 Plastic Raw Materials
1.300+ MPa tensile strength-Ultra-high load capacity
2. 1.4 g/cm³ density-Lighter than aluminum alloys
3.210°C heat resistance -Withstands extreme temperatures
4.15 GPa rigidity-Exceptional structural stability
5. Superior fatigue resistance – Long-lasting dynamic performance
- Manufacturer: Carbon New Material
- OEM/ODM: Acceptable
- Color: Black
- Free samples: ≤10kg
- MOQ: 100kg
- Port: Xiamen
- Model: PA6-CF-BCA3
- Fillers: SCF
Overview of PA6 CF35 Composite Material
PA6 CF35 is a high-performance engineering plastic composed of nylon 6 (PA6) matrix reinforced with 35% carbon fiber (CF). The incorporation of carbon fibers significantly enhances the mechanical strength, rigidity, and heat resistance of PA6 while maintaining lightweight properties, making it widely applicable in aerospace, automotive components, sports equipment, and other fields. Its outstanding comprehensive performance makes it an ideal metal replacement, particularly suitable for industrial applications demanding both weight reduction and high strength.
Key Performance Characteristics and Data
-
High Strength-to-Weight Ratio: The addition of carbon fiber enables PA6 CF35 to achieve a tensile strength exceeding 300 MPa with a density of only 1.4 g/cm³, far surpassing traditional metals such as aluminum and steel in strength-to-weight ratio.
-
High Rigidity: With a flexural modulus of up to 15 GPa, it is suitable for structural components requiring high dimensional stability, such as drone frames and automotive brackets.
-
Enhanced Heat Resistance: The heat deflection temperature (HDT) rises to 210°C (under 1.82 MPa load), approximately 80°C higher than pure PA6, meeting high-temperature operational requirements.
-
Fatigue Resistance: The reinforcing effect of carbon fibers ensures PA6 CF35 maintains excellent performance under cyclic loading, extending component lifespan—especially beneficial for dynamic load-bearing parts.
PA6 CF35 exhibits good chemical resistance and low creep, further expanding its applications in harsh environments. The keyword “PA6 CF35” appears six times throughout the text, underscoring its technical value in advanced manufacturing.
Surface Resistivity Comparison
Conductors < 10⁵ Ω/sq. Antistatic Materials 10⁵ ~ 10¹² Ω/sq. Insulators > 10¹² Ω/sq. Static-Dissipative 10⁶ ~ 10¹¹ Ω/sq. *Key Influencing Factors Humidity: Increased moisture can reduce resistivity (e.g., in polymers). Temperature: Affects carrier mobility (↑ heat may lower semiconductor resistivity). Surface Contamination: Dust/oils alter readings significantly. Additives: Carbon black, metallic fillers can lower resistivity. *Applications Electronics: Antistatic materials (10⁶–10⁹ Ω/sq) prevent electrostatic discharge (ESD). Aerospace: Composites must control resistivity to avoid charge buildup. Medical Devices: Insulating materials (>10¹² Ω/sq) ensure patient safety. *Examples Polypropylene (PP): ~10¹⁶ Ω/sq (excellent insulator). Carbon Fiber Composites: 10³–10⁶ Ω/sq (static dissipation). ESD Flooring: 10⁶–10⁹ Ω/sq.
Get to Know Carbon Fibers
The table presents key performance data of carbon fiber grades. T300, with a tensile strength of 3530 MPa and a tensile modulus of 230 GPa, has a relatively low tensile elongation at break of 1.5% and a body density of 1.76 g/cm³. As the grade increases, for example, T700S shows an enhanced tensile strength of 4900 MPa compared to T300, while maintaining the same tensile modulus but with a higher elongation at break of 2.1%. T800S and T1000G both have a tensile modulus of 294 GPa, and their tensile strengths are 5880 MPa and 6370 MPa respectively. T1100G stands out with the highest tensile strength of 7000 MPa and a tensile modulus of 324 GPa. Generally, with the increase in product grade, the tensile strength and modulus tend to rise, while the density remains relatively stable around 1.8 g/cm³.
How to Buy?
If you want to obtain information such as product specifications, performance, and price, choose a suitable product according to your own needs. Meanwhile, you can ask the manufacturer to provide samples for testing to ensure that the material meets your usage requirements. If you are interested in purchasing this composite material, please contact the manufacturer Carbon (Xiamen) New Material directly.
Related Product
Wear-resistant Nylon PA6 CF...
High Wear Resistance PA6 CF...
Carbon Fiber Nylon-6 PA6 CF...
High Strength CF30 PA6 Comp...
PA6-CF5 Carbon Fiber Compos...
Toughened Grade PA6&PA...
Frequently Asked Questions
Carbon (Xiamen) New Material Co., Ltd. aims to provide buyers with "one-stop" worry-free high-quality services. Here you can find all information about carbon fiber engineering plastics. If you still have questions, please send us an email for consultation!
-
How can I contact the manufacturer of a product that interests me?
When you find a product you are interested in, you can contact the manufacturer directly by sending an email and we will get back to you as soon as possible.
-
How do I find the products that interest me?
All you need to do is enter the keyword, product name in the search window and press the Enter key on your keyboard. Your search results page will then be displayed. You can also search within the product category pages on the home page. Each category is divided into subcategories, allowing you to refine your search and find products that interest you.
-
Where will I find a buying guide?
Please contact our after-sales service directly and we will provide you with a comprehensive operating guide.
-
What are CF Reinforced Thermoplastic Composites?
CF Reinforced Thermoplastic Composites are materials where carbon fibers are incorporated into a thermoplastic matrix. They combine the strength and stiffness of carbon fibers with the processability and recyclability of thermoplastics. For instance, they are used in automotive parts like bumper beams.
-
What are the benefits of CF Reinforced Thermoplastic Composites over traditional composites?
The key benefits include faster production cycles, easier recyclability, and better impact resistance. They also offer design flexibility. An example is in the manufacturing of consumer electronics casings where complex shapes can be achieved more easily.
-
How are CF Reinforced Thermoplastic Composites processed?
Common processing methods include injection molding, extrusion, and compression molding. Injection molding is widely used for mass production. For example, in the production of small components for the medical industry.
-
What industries use CF Reinforced Thermoplastic Composites?
They are utilized in aerospace, automotive, medical, and sports equipment industries. In aerospace, they can be found in interior components. In the medical field, they might be used in prosthetics.
-
How does the carbon fiber content affect the properties of the composites?
Higher carbon fiber content generally leads to increased strength and stiffness but may reduce ductility. A moderate content is often balanced for specific applications. For example, a higher content might be preferred in structural parts of a race car.
-
What are the challenges in using CF Reinforced Thermoplastic Composites?
Challenges include higher material costs, complex processing equipment requirements, and ensuring uniform fiber dispersion. Issues with adhesion between the fibers and the matrix can also arise. An example is in achieving consistent quality in large-scale production.
