PA6 LCF High Strength Engineering Plastic Rods
PA6 LCF is a high performance thermoplastic reinforced with long carbon fibers, delivering superior stiffness, dimensional stability, and heat resistance (up to 180°C). Designed for automotive, aerospace and industrial applications, it offers optimal strength-to-weight ratio, chemical resistance and processability for structural components.
- Model: PA6-LCF-BCA1
- Matrix Material: Polyamide 6 (PA6)
- Reinforcement: Long Carbon Fiber
- Processing Method: Injection/Compression Molding
- Packaging: 25kg/bag
PA6 LCF | Long Carbon Fiber Reinforced Nylon 6 Engineering Plastic
PA6 LCF is a high-performance, semi-crystalline engineering thermoplastic reinforced with long carbon fibers, offering superior stiffness, strength, and dimensional stability compared to short-fiber or unfilled PA6 grades. With its exceptional mechanical properties, thermal resistance, and processability, PA6-LCF is ideal for demanding applications in automotive, aerospace, and industrial systems where structural integrity and lightweight performance are critical.
Compared to short-fiber reinforced PA6, PA6-LCF provides higher impact resistance, better fatigue endurance, and improved creep resistance while maintaining excellent chemical and thermal stability.
Core Performance Highlights
1.Mechanical Properties
*Fiber Reinforcement: Long carbon fibers (optimized dispersion for maximum strength)
*Tensile Strength: ~180–220 MPa
*Flexural Modulus: ~12–15 GPa
*Elongation at Break: ~2.0–3.0%
*Notched Izod Impact: ~90–120 J/m
2.Thermal Resistance
*Heat Deflection Temperature (HDT): ≥ 220 °C
*Continuous Use Temperature: Up to 180 °C
3.Environmental & Chemical Durability
*Moisture Absorption: ~0.8–1.2% (lower than standard PA6)
*Chemical Resistance: Excellent resistance to oils, fuels, coolants, and industrial chemicals
Target Applications
1.Automotive & Aerospace
Structural brackets, engine covers, transmission components
→ PA6-LCF provides high strength-to-weight ratio, reducing vehicle weight while maintaining durability.
2.Industrial Machinery
Gears, bearings, pump housings
→ PA6-LCF offers excellent wear resistance and load-bearing capacity for long-term performance.
3.Electronics & Electrical
Connectors, circuit board mounts, housings
→ PA6-LCF ensures dimensional stability and EMI shielding properties.
Strength Comparison Between PA6 and PA6 LCF
PA6 LCF (long carbon fiber reinforced) delivers substantially greater mechanical strength and stiffness versus standard PA6. The long carbon fiber reinforcement significantly improves tensile strength, flexural modulus, and impact resistance, making PA6 LCF ideal for structural components under high stress. While standard PA6 works well for general-purpose applications, PA6 LCF provides enhanced performance for demanding industrial applications requiring superior strength-to-weight ratio and fatigue resistance.
